Product Description
Product Specifications
| ANSI Code 1 | S68 |
| Applications | Roadway, Parking lot, Retail, Security, Street, Wall Wash |
| Ballast Type | High Pressure Sodium |
| Brand | ProLume |
| CSA | N |
| Capacitor Included | N |
| Case Height | 2.22 |
| Dimmable | N |
| Fuse Rating-120V (Amps) | 4 |
| HTS code | 8504100000 |
| Included-mounting bracket | Y |
| Inner UPC | 807154551040 |
| Input Frequency (Hz) | 60 |
| Input Short Circuit Current-120V (Amps) | 0.3-0.9 |
| Input Volts (V) | 120 |
| Lamp Type | HID Ballast |
| Lamp Wattage | 50 |
| Markets | Commercial, Industrial |
| Nominal Open Circuit Volts | 120 |
| Number of Lamps | 1 |
| Open Circuit Current- 120V (Amps) | 0.9 |
| Operating Current-120V (Amps) | 1.2 |
| Primary Lamp | LU70 |
| Product Code | S68/50R/120/K |
| Product Description | 50W LU S68 120V KIT |
| Product Number | 55104 |
| SS BUY PKG | 20 |
| Secondary Short Circuit Current - 120V (Amps) | 1.2-1.9 |
| Specification Sheet | |
| Start Type | Standard |
| Starting Current - 120V (Amps) | 0.7 |
| TITLE20 Y/N | Y |
| Warranty (Yrs) | 2 |
| Wattage (W) | 61 |
